1, The machine body is constructed from thick-walled steel pipe made. Bed body through finite element analysis (FEA) and design for the machine to provide a rigid and stable platform, and all parts of the bed body before processing has been eliminate stress.
2, All locating bearings, ball screws, linear guides, rack, machine control system has centralized by automatic lubrication system maintenance. This is a unanimously recommended approach by ball screws and linear guides manufacturer.
3, The main components of the models are made of top international brands, such as Japan Yaskawa AC servo drive system, Italy HSD spindle, Italy MC7 +4 row drilling, pumps imported from Germany.
4, Each machine standard with a 10 knife-bit compatibility knife magazine, the magazine  is controlled by SYNTEC CNC system 9401 or LNC-520H that made tool change fast and reliable.
5, Vacuum adsorption countertops is divided into  six processing regions, can single-zone processing or processed simultaneously, that increased processing efficiency.
6, Z axis is supported by a pneumatic balancing system, pneumatic system is a closed loop balance, its role is to minimize gas consumption operation.
7, With integrated industrial PC LNC-520H control system to ensure the machine speed, high-precision machining.

Scope:
The machine is suitable for a wide range of complex processing, more suitable for the production of items: MDF, cabinet doors, computer tables, furniture and other non-metallic materials and non-ferrous metals: such as copper, aluminum engraving process.

Technical parameters:
1 X, Y, Z travel: 1300 × 2500 × 200mm
2 Platform Size: 1320x3100mm
3 Processing accuracy: ± 0.02mm
4 Repeat positioning accuracy: ± 0.01mm
5 countertop structure: Bakelite vacuum
6 X, Y, Z drive structure: XY: linear guide rail + rack, Z: linear rail + screw
7 Self consumption power: 2KW
8 Max empty line speed: 45000mm/min
9 Maximum operating speed: 15000mm/min
10 Spindle Power consumption: 4.5KW water-cooled standard
11 Spindle speed: 6000-24000r/min
12 Drive system: three-phase stepper system
13 Operating voltage: 380V/50/60Hz
14 Run the command: G code
15 Flash: 128M (U Disk)
16 Interface: USB
17 Control System: DSP System
19 Shank: ER20
20 Software Support: Type3, Artcam, Ucancam, Caxa, Mastercam, UG
21 Working environment: Temperature: 0 ° ~ 45 ° C, relative humidity: 30% to 75%
22 Overall dimensions: 1700 × 3150 × 1750mm
23 Net weight: 1000Kg
24 Gross Weight: 1200Kg
