Features:
◎ Compatible with Type3/Artcam/Castmate/Proe/UG / Wentai and other variety of domestic and international CAD / CAM software
◎ With power outages, tool breakage continued carving function.
◎ Adopt industrial pipe welding, special instruments resonance to eliminate stress, large, high-precision gantry milling processing key size. High strength, good rigidity, precision is guaranteed.
◎ Y direction dual motor drive,strong power, fast.
Applicable industries:
Suitable for advertising logos, signs, light box 3D mold making, casting mold, carpentry 3D ornamental engraving technology, furniture manufacturing, wave plate, aluminum plate aluminum cutting large architectural model making and other industries.
Optional: 4000W or more power imported spindle, dust cleaning equipment, vacuum adsorption, automatic tool change system.
Customizable: 3000 × 1500mm, 3000 × 1800mm, 4000 × 2000mm models.
Technical parameters:
X, Y axis travel: 1300X2500mm
Z axis travel: 200mm
Platform Size: 1480X3000mm
Maximum road speed:> 25m/min
Clamping Type: vacuum adsorption
Processor: DSP / frequency 100MHz
Interface Interface: USB
Carving instructions: G code * u00 * mmg * plt...
Software operating environment: DSP
Power (spindle): 1840W
Working Voltage: AC 380V 50Hz
Spindle power: 4.5/5.5KW (domestic water)
Spindle speed: 0-24000rpm
Work: steper
