Features:
1, Adopt imported linear square rails, double four ball slider, loading capacity, smooth operation.
2, Optional high-speed water-cooled motor which spindle bearings imported from Japan NSK. High spindle power, stable performance.
3, USB interface DSP operating system, handle operation, the operation more simple, design more humane.
4, Compatible type3/Actcam/Castmate / Wentai and other CAD / CAM design software.
5, six partitions vacuum adsorption countertops, which can effectively adsorb different size plates.
Applicable industries:
Woodworking: three-dimensional wave board processing, cabinet doors, wooden craft, paint doors, screens, windows and milling machining fan-shaped carving furniture products.
Technical parameters:
X, Y axis travel:1250X2450mm
Z axis travel:> 110mm
Platform size: 1440X3000mm
The maximum operating speed: 14m/min
Maximum engraving speed: 8m/min
Resolution: 0.05mm
Repeat positioning accuracy: 0.005mm
Feeding height: 120mm
Engraving Command:G code *. U00 *. Mmg *. Plt
Software operating environment: windows98/2000/XP
Power (without spindle) :1500W
Operating voltage: AC 220V 50Hz
Spindle power: 2.2KW
Spindle speed: 24000rpm
Operating mode: steper
Total Weight: 700kg
