Features:
1).Double motors and drivers of Y axis ensure steady movement.
2).Rack gear transmission ensures fast speed and high accuracy.
3).Imported square rail ensures high accuracy and heavy workload.
4).Adopt vacuum system, made by advanced international technology, with double cavities, configured with vacuum pump of strong adsorption, can adsorb different size materials.
5).The vacuum area adopts solenoid valve control, controlling the start and stop of vacuum conveniently by one single touch.
6).Humanized design of vacuum table with T slot and clamps can adsorb or clamp the work piece, the operation is convenient.
7).Intelligent protection of working table can avoid damage resulted from the wrong operation.
8).Intelligent overrunning protection can avoid mechanical collision when set graphic exceeds processing size.
9).Automatic lubrication system fulfills the periodic lubrication maintenance just one single touch.


Technical parameters:
X, Y axis travel: 1300 × 1300mm
Maximum traveling speed:> 25m/min
Processor: DSP / frequency 100MHz
Interface Interface: USB
Carving instructions: G code * u00 * mmg * plt...
Software operating environment: DSP
Power (spindle): 1840W
Working Voltage: AC 380V 50Hz
Spindle power: 1.5KW × 4 (domestic water)
Spindle speed: 0-24000rpm/min
Working methods: steper
