Machine performance:
Bed firmly: Bed body using integrated cast iron processing, robust and reliable, no deformation.
Precision ball screw: Machine X-axis, Y-axis, Z axis all adopt high precision ball screw nut imported from Germany, small gap.
Guide bearings: a square linear guide, linear ball bearings imported from Japan
Spindle motor power: water-cooled spindle motor variable frequency motor, can work long hours, both vigorously cutting, can be fine carved.
Automatic tool: with Automatic tool setting function, easy to operate.
Power-off memory: When processing if a sudden power failure or malfunction, with memory function, can continue to carve in the original location, to save material.
Scope: glass crafts, architectural models, advertising engraving, sign making and so on.

Mechanical precision: 0.0125MM.

Machine parameters:
Processing range: 1300MM * 2500MM * 150-200MM
Net machine weight: 750KG
Total weight: 900KG
Idle speed: 6000MM/MIN
Spindle motor: 24000 rpm / MIN, 1500W water-cooled inverter
Instruction: G command, PLT, HPGL2D, 3D, etc.
The spindle motor tool range :3.175-6MM
