1,Industry:
Mold industry: can engrave all kinds of molds, lost foam, automotive foam molds, large wooden model ships, aviation wooden mold, propeller, trains wood molds.

2, Feature:
◆ Use SYNTEC CNC system, high precision and fast speed.
◆ Imported four-row ball bearing, widening linear guide, self-lubricating block. When carving equal force in all directions to ensure the accuracy and mechanical strength.
◆ Z axis travel can be heightened to 1 m, processing, large format, suitable for processing large ultra thickness of the material.
◆ Intelligent processing cross-border protection feature that prevents large design files when processing caused by mechanical impact.
◆ Diversified control can control the processing speed, idling speed, cutting speed, greatly improving the quality of processed products and processing efficiency.

3,Technical parameters:
Processing area: 1300 * 2500mm
Spindle power: 2.2/3/4.5kw
Feeding height :800-1000mm
The fastest processing speed: 45m/min
Spindle speed :0-18000rpm
Repeatability: ± 0.05mm
Precision: ± 0.05mm (according to a different tool case may be)
Control system: Weihong or SYNTEC
