Features:
1, This model is suitable for 2-3 pattern carving knife engraving and milling, processing of a variety of pattern without tool change, the program automatically executed , and its main feature is a small investment funds, high-yield and low maintenance, easy to operate, for CNC operator weak person, programming operation is very easy.
2, Equipped with advanced DSP control handle, control zone automatic multi-layer 3D processing, can be fast, smooth three-dimensional processing, carving or cutting, and can be achieved offline operation.
3, Compatible type3/Artcam/Castmate / Wentai and other CAD / CAM engraving machine design software.
4, Adopt imported linear square rails, double four ball slider, loading capacity, smooth operation, high precision, long life, high precision imported ball screw, the knife precision.
5, Suitable for a variety of materials for mass production.
Applicable industries:
Woodworking: three-dimensional wave board processing, cabinet doors, wooden craft, paint doors, screens, windows and milling machining fan-shaped carving furniture products.
Performance parameters:
X, Y axis travel: 1300 × 2500mm
Z axis travel: 200mm
Platform Size: 1300 × 2500mm
Maximum traveling speed> 20m/min
Clamping Type: vacuum by suction
Processor: DSP / frequency 100MHz
Interface Interface: USB
Carving instructions: G code * u00 * mmg * plt...
Software operating environment: DSP
Power(without spindle): 3000W
Operating voltage: 380V 50Hz
Spindle power: 4.5KWx2 (domestic water)
Spindle speed: 0-24000rpm
Working methods: steper
