Features:
Efficient work: curves, straight-line speed can maintain consistent, operating speed up to 25 m / min.
Advanced systems: using advanced DSP control system, standard 128M storage space,can save 30 processing files simultaneously, and support U disk directly output (donated 256M U disk); compatible Type3/Artcam/Proe/UG / Wentai and other kinds of international CAD / CAM software.
Perfect structure: industrial machine structure, equipped with high-power spindle motor and imported high-density linear square rails.
Simple operation: using advanced USB interface, all working offline; have power restored, breakpoint continued carving, processing time prediction, automatic tool setting and other human functions.
Scope:
Suited for high efficiency production of 3D stenciling process, wave board processing, wooden doors, MDF, solid wood furniture, sculpture, mural art of wood carving, paint the door engraving, advertising signs, PVC plate cutting, hole literally cutting, pressure grams force cutting, plastic molding, millwork, LED / neon groove, crystal plates, crafts, carvings and iron, copper, aluminum and other metals.
Technical parameters:
Processing Size: MD-1515 1500 * 1500 * 150mm
MD-1325 1300 * 2500 * 150mm
MD-1520 1500 * 2000 * 150mm
MD-1630 1550 * 3000 * 150mm
MD-2030 2000 * 3000 * 150mm
Spindle motor: 3KW motor constant power inverter water ice
Operating speed: 25000mm/min
Spindle speed: 6000-24000rpm
Tool: ◎ 3.175, ◎ 4, ◎ 6, ◎ 12.7mm (optional optional)
Instruction format: HPGL, G-code
Resolution: 0.01mm
