Features:
◎ Compatible with Type3/Artcam/Castmate/Proe/UG / Wentai and other variety of domestic and international CAD / CAM software
◎ With power outages, tool breakage continued carving function.
◎ Adopt industrial pipe welding, special instruments resonance to eliminate stress, large, high-precision gantry milling processing key size. High strength, good rigidity, precision is guaranteed.
◎ Y direction dual motor drive,strong power, fast.


Technical parameters:
X, Y axis travel: 1300X2500mm
Z axis travel: 200mm
Platform Size: 1480X3000mm
Maximum road speed:> 30m/min
Clamping Type: Vacuum adsorption
Processor: DSP / frequency 100MHz
Interface Interface: USB
Carving instructions: G code * u00 * mmg * plt...
Software operating environment: WIN98/WIN2000/WINXP
Power (without spindle): 4000W
Operating voltage: 380V 50Hz
Spindle power: 5KW (domestic water)
Spindle speed: 0-18000rpm/min
Working methods: servo
