1) Bed body structure: whole cast iron
2) Rail types: XYZ axis linear square rail
3) Transmission mode: XY-axis use rack drive, Z axis precision ball screw has
7) Maximum placed material height: 100mm or bigger choice
8) Cut thickness of material: ≤ 40mm
9) Max idle speed: 25000mm/min
10) Working speed: 0 - 10000mm/min
11) Mechanical precision: 0.01mm
12) Applicable Software: type 3, Artcut Wentai carving 2002, Wentai V8, Artcam
13) Total power: 6kW
14) External power: AC 220/50/60Hz / adsorption countertops using AC380V
15) Drive Type: stepper motor (XYZ-85BYG motor, Y axis uses double-motor)
16) Memory: None or DSP handle control, you can choose to use U disk
17) Spindle motor: 2.2kW (Ф100mm) water-cooled variable frequency motor (optional 3kW or larger)
18) Spindle speed: 0 - 24000rpm
19) tool chuck diameter: Ф3.175mm, 4mm, 6mm (high-power spindle can choose to use 8mm, 10mm, 12mm, 12.7mm tool)
20) Control system: Weihong NCSTUDIO or with DSP handle (can use U disk)
21) File command: G code, u00, mmg, plt
22) Machine operating temperature: 0 - 45 ° C
23) Operating Humidity: 30% - 75%
