Features:
1, Using the high-power water-cooled brushless frequency conversion motor, high precision, long life, smooth operation, water-cooled motor can be long running, after continuous work, changing the water as long as you can, whether it is carving or cutting are handy.
2, Whole cast iron bed body, flat-screen whole processing to ensure its parallelism, squareness, flatness, concentricity requirements.
3, Using imported linear square linear guide rail, double four ball slider, loading capacity, smooth operation, high precision, long life.
4, The control method is connected to the computer, using the breakpoint memory, guaranteed in the accident (tool breakage) or the next day, the unique multiple workpiece datum setting multiple ways, the workpiece can be prioritized processing, more humane, but also programmable control engraving cutting, CNC better.
5, Z-axis travel greater than 1 m, the thickness can be carved up to 0.5 meters.
6, Y-axis dual-motor drive, ensuring the smooth operation of the machine evenly.
7, Software compatibility, compatible type3/Artcam/Castmate / UG / Wentai and other CAD / CAM design software.
8, Intelligent protection for working table that can prevent misuse or software errors countertops may cause damage, intelligent processing cross-border protection to prevent over processing format layout design of mechanical collision caused the phenomenon

Mechanical performance parameters:
X, Y, Z axis positioning accuracy: 0.05mm
X, Y, Z axis repeatability: 0.05mm
X, Y, Z axis working stroke: 1300 × 1800 × 500mm
Table size: 1300 × 1800mm
The maximum workload weight: 300kg
Table withstand deformation: <0.02/120Kg
Bed body weight 1500 Kg
Spindle motor: 6000-24000 rpm
Rapid traverse speed: 25m/min
Maximum cutting feed speed: 10m/min
Drive system: Stepper
Operating voltage: AC380V/50HZ
Overall dimensions: 1600 × 2200 × 2500mm
