Features:
Gantry moving, machine using seamless welded steel structure, strong rigidity no deformation.
This machine adopts imported high-speed spindle, automatic tool change function, automatic change 8 tool; Taiwan's industrial CNC automatic tool change system, Japan servo motor, high precision and speed.
Advanced file preprocessing functions to help users to correct errors in processing documents.
Advanced three-dimensional curve prediction method, smooth line to ensure that the curve of speed and accuracy.
Variety Optional: can be installed horizontal milling, vertical drilling, horizontal drilling, cut saw, hob, two axis, three-axis and automatic tool change and other features. Front and side capable of drilling, drilling, carving, engraving, face milling work. Meet the needs of medium-sized processing enterprises.
Technical parameters:
X, Y, Z axis positioning accuracy: ± 0.05
X, Y, Z axis repeat positioning precision: ± 0.05
X, Y, Z axis working stroke: 2440 × 1220 × 200mm
Table size: 2440 × 1220mm
Maximum speed: 60m/min
Spindle speed: 6000-24000rpm
Spindle power: 8Kw
System resolution: ± 0.001mm
Vacuum adsorption capacity: 230m ³ / h
Weight: about 2800Kg
